Single-Phase ATS/Switched PDU with LX Platform Interface, 16 Outlets, 12 ft Cord

Provides a redundant power option for single-corded network devices. Dual input cords support separate connection to primary and secondary power sources. The ATS will normally maintain continuous output to all outlets as derived from the primary input cable. If the primary power source becomes unstable or fails altogether, the ATS will switch over to the secondary power source until the primary input is restored and stable. Features include individually controllable output receptacles and built-in network interface. Super-fast switchover between primary and secondary power sources occurs within milliseconds.
$901.69USDRetail $1,128.82
  • Provides a redundant A/B power option for non-redundant networking equipment with a single input power cord.
  • Features ATS (auto-transfer switching).
  • Switched PDU features enable programmable or real-time power control of individual outlets via built-in network interface.
  • Digital display continuously reports total output power consumption in amps.
  • Separate primary & secondary inputs connect to any two compatible power sources.
    • Manufacturer:
    Tripp Lite
    Item:
    PDUMH20ATNET
    UPC Code:
    037332136411
    Condition
    New
    Extended Warrenty
    1 Year Extended Warrenty$180.34
    $901.69USD EA
     $1,128.82
    0 Reviews
    Availability In Stock
    Great Deals Everyday

    You may be also interested

    Product description

    Tripp Lite PDU Switched ATS 120V 20A 5-15/20R 16 Outlet L5-20P Horizontal TAA - 16 x NEMA 5-15/20R - 2.4kVA - 1U Rack-mountable
    16 x NEMA 5-15/20R - 2.4kVA - 1U Rack-mountable

    Specifications

    Brand Name
    Tripp Lite
    Certifications & Standards
    • 60950
    • Class A
    • TAA Compliant
    Color(s)
    Black
    Color(s)
    Black
    Color(s)
    Black
    Compliance Standards
    UL Listed
    Compliance Standards
    UL Listed
    Compliance Standards
    UL Listed
    Compliance Standards
    NOM
    Compliance Standards
    NOM
    Compliance Standards
    NOM
    Compliance Standards
    RoHS Compliant
    Compliance Standards
    RoHS Compliant
    Compliance Standards
    RoHS Compliant
    Cord Length
    12 ft
    Cord Length
    12 ft
    Cord Length
    12 ft
    Cord Length
    12
    Cord Length
    12
    Cord Length
    12
    Country of Origin
    Taiwan
    Country of origin
    Taiwan
    Country of origin
    Taiwan
    Current
    20 A
    Current
    20 A
    Current
    20 A
    Depth
    14.5"
    Depth
    14.5"
    Depth
    14.5"
    Environmental Certification
    RoHS
    Environmentally Friendly
    Yes
    Height
    1 3/4"
    Height
    1 3/4"
    Height
    1 3/4"
    Height
    1.8"
    Height
    1.8"
    Height
    1.8"
    Input voltage
    120 V AC
    Input voltage
    120 V AC
    Input Voltage
    120 V AC
    Length
    17 1/2"
    Length
    17 1/2"
    Length
    17 1/2"
    Limited Warranty
    2 Year
    Management
    • Integrated Automatic Transfer Switch (ATS) allows PDU to operate from secondary input source when primary input fails
    • Sequential outlet power-on prevents inrush-related equipment interaction on startup
    • Programmable or real-time monitoring and outlet power control via secure web/network interface
    Manufacturer
    Tripp Lite by Eaton
    Manufacturer Part Number
    PDUMH20ATNET
    Manufacturer Website Address
    http://www.tripplite.com
    Marketing Information
    Tripp Lite Switched ATS / Auto Transfer Switch provides a redundant power option for single-corded network devices. Dual input cords support separate connection to PRIMARY and SECONDARY power sources. The ATS will normally maintain continuous output to all outlets as derived from the primary input cable. If the primary power source becomes unstable or fails altogether the ATS will switch over to the secondary power source until the primary input is restored and stable. The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser SNMP telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4 IPv6 HTTP HTTPS SMTP SNMPv1 SNMPv2 SNMPv3 telnet SSH FTP DHCP BOOTP and NTP. Switched PDU features include individually controllable output receptacles and built-in network interface. Super-fast switchover between primary and secondary power sources occurs within milliseconds. ATS functionality is supported by any two compatible AC power sources regardless of phase angle to support a variety of advanced redundant power networking applications. Enables fault tolerant hot-swappable UPS protection when used with a single UPS and fully redundant UPS protection when each cord is connected to a separate UPS system. In a two-UPS environment the primary input cable must be supported by a full time sine wave UPS with zero transfer time. Tripp Lite SmartOnline series is highly recommended for use as the primary UPS in a two-UPS application. ATS configurations utilizing separate mains circuits backup generators and even separate utility power grid feeds are fully supported. On-board ATS processor constantly evaluates power quality on both input sources to prevent transfer to the secondary source when unavailable or of lower quality than the primary source. Front input LED's display primary or secondary power availability.
    Material(s)
    Steel
    Material(s)
    Steel
    Material(s)
    Steel
    Mount Type
    Rack-mountable
    Number of Cord/Cable
    2
    Number of Outlets
    16
    Number of Outlets
    16
    Number of Outlets
    16
    Package Contents
    • PDUMH20ATNET PDU Switched ATS 120V 20A 16 Outlet
    • PDU with attached L5-20P input power cord
    • Detachable C19 to NEMA L5-20P 12 ft/3.6m power cord for optional secondary input
    • Two NEMA L5-20R to NEMA 5-20P plug adapters
    • User manual with warranty information
    Package_Includes
    Input Power Cord; Detachable 12 ft Power Cord; 2 NEMA L5-20R to NEMA 5-20P Plug Adapters; User Manual with Warranty Information
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
    PDU Type
    Switched
